Old October 4th, 2005, 12:17 AM   #1 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
How to Polish the Rear Half of a 98, 98c, and 98 Pro

Reason : To reduce the friction between the Hammer and the body, this then increase the rate of fire(some what) and the performance of the gun
Notice:
  • Be sure to read and understand the instructions be for attempting this on your gun
  • Picts are from my 98c so Newer 98s will very slightly in the appearance of the shells and if yours has the ACT system be careful of the holes for the two small pins.
Tools/Supplies Needed
  • 320 Grit Sand Paper
  • 600 Grit Sand Paper
  • Machine Oil
  • Non-gell Tooth Paste (Optional)
  • Screwdriver ( IF you have the RT installed)
  • The Alen Keys that came with the gun or matching Sizes
  • Clean Rag (Things are going to get dirty)
Instructions
  1. Disassemble the gun and remove every thing from the body shells even the power tube and RT piston.
  2. With the rag clean out all dirt and paint from the shell halves
  3. Now before go on I will be using the right shell as an example for polishing the shells
  4. Here is the unpolished right shell

    Tippmann does a good job casting the shells but they are fairly rough.
  5. Now put a few drops of oil on the back half behind were the powertube would be.
  6. Take the 320 Grit paper and start to sand to remove most of the bige scratches

    You want to work on the area were the seer rests and the "trougth" that the hammer travels in.
  7. Wipe oil and grit off the shell
  8. Repeat Steps 6-7 with the 600 grit sand paper
  9. At this point the shell should look like this and feel smooth to the touch.
  10. This next step is optional
  11. Put some tooth paste on you finger and rub down the "trought" a few time and be sure to get all of the tooth paste cleaned out of the shell
  12. Now we will Polish the Hammer
  13. Remove the O-Ring from the Hammer and put it in a safe place (Safer then you pocket)
  14. Clean the hammer as you did the shells
  15. Put a few drops of oil on the hammer
  16. Lightly sand with the 320 grit paper
    Here is a comparison of a half sanded hammer (top has been sanded).
  17. Clean the Oil and grit off the hammer
  18. Repeat steps 15-17 with the 600 grit sand papper
  19. Optional: do a final Polish with the tooth paste like you did on the shells
  20. Clean the parts one more time to besure that all the grit and dirt has been removed
  21. Reasemble your 98 and enjoy your more efficient and better preforming gun

An other option that i did not show is how to polish the sides of the seer.

Feel free to post any improvments, questions, or comments that you may have.

EDIT:
Here is a good picture of when i finished mine withjust the sand paper.


Slight update 8/13/07
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche

Last edited by Mortisdeum; August 14th, 2007 at 12:27 AM..
Mortisdeum is offline View My Blog!   Reply With Quote
Sponsored Links
Advertisement

Old October 4th, 2005, 01:19 AM   #2 (permalink)
Screaming Koala

Torch's Avatar

Join Date: Nov 2004
Location: Bentleyville, PA
Posts: 4,685
Blog Entries: 1
Good post.

Despite this being covered briefly in one of the mod threads (that used to be sticky), we should probably compile as much of these things as we can since model98.net seems to be down for the count.

I'd add...If you own a dremel or just have a lot of time to do this by hand, a final run with the dremel polishing wheel and mothers or another brand of aluminum polish works good. If you do it by hand, expect it to take a while. Really gives the surface mirror shine.

I sanded my hammer once, it smoothed it out but it seemed to grow some sort of oxide on it afterwards. My best guess is that it wasn't stainless steel, but rather zinc plated steel and it started to rust or otherwise react with something after I sanded it. I have no real proof that this is right, but something to look for at least.

Polish the front bolt area and the link arm path as well? I always try to just for the hell of it.
__________________
"RD&D - Research, Development, and Design. - If its not broken, fix it anyway."
T.O.G. #131 - P.O.G. #16 - C.O.G. #145
Rate the:
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Torch is offline View My Blog!   Reply With Quote
Old October 4th, 2005, 01:24 AM   #3 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
Quote:
Originally Posted by Torch
Good post.

Despite this being covered briefly in one of the mod threads (that used to be sticky), we should probably compile as much of these things as we can since model98.net seems to be down for the count.

I'd add...If you own a dremel or just have a lot of time to do this by hand, a final run with the dremel polishing wheel and mothers or another brand of aluminum polish works good. If you do it by hand, expect it to take a while. Really gives the surface mirror shine.
...
...
Polish the front bolt area and the link arm path as well? I always try to just for the hell of it.
Thanks for the aproval

As for the Dremel it is a good idea but most people don't have them so in the guid i use Tooth paste case it is a polishing abrasive (takes scratchs off the back of my iPod nicely too)

As for the front and the linking arm I kinda ran out of time befor i had to goto work. But doing it is the same basic steps
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche
Mortisdeum is offline View My Blog!   Reply With Quote
Sponsored Links
Advertisement

Old October 4th, 2005, 07:41 AM   #4 (permalink)
Fast and Furious baby!

PoisonMushroom's Avatar

Join Date: Aug 2005
Location: Cleveland, TN
Posts: 599
Quote:
Originally Posted by Mortisdeum
...takes scratchs off the back of my iPod nicely too...
Is that true? If so, then I really need to do that....
__________________
System X NME LE - Black w/ blue accents
Blue Halo B w/ Rip
68/45 Crossfire tank
CP ASA
NDZ low rise feedneck
PoisonMushroom is offline View My Blog!   Reply With Quote
Old October 4th, 2005, 02:33 PM   #5 (permalink)
Moderator

Alpha's Avatar

Join Date: Dec 2003
Posts: 12,110
Mothers Mag and ALuminum polish will do a LOT for you. It really goes a long way.
__________________

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Alpha is offline View My Blog!   Reply With Quote
Old January 9th, 2006, 09:52 PM   #6 (permalink)
Registered User

Join Date: Dec 2005
Posts: 120
excellent thread with great pics
Dasminkar is offline View My Blog!   Reply With Quote
Old January 10th, 2006, 06:26 AM   #7 (permalink)
G-Vegas Baller

GvegasPB's Avatar

Join Date: Nov 2005
Location: NC
Posts: 226
Awesome Thread I did this about a week ago, and I love the results.
__________________
Tippmann Owners Club Member #292

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
GvegasPB is offline View My Blog!   Reply With Quote
Old January 12th, 2006, 12:00 AM   #8 (permalink)
Established Member

Join Date: Jun 2005
Posts: 83
awesome

this is is great i just did it and it is awesome , smooth and good.
zeesui is offline View My Blog!   Reply With Quote
Old January 14th, 2006, 09:22 PM   #9 (permalink)
probably high

skapunkin's Avatar

Join Date: Dec 2004
Posts: 533
Quote:
Originally Posted by Alpha
Mothers Mag and ALuminum polish will do a LOT for you. It really goes a long way.
In place of 300/600 sand paper or in conjunction with?
__________________
ska's 98C · lapco bigshot 8in · dop powertube · tippman exchamber · polished internals · shocktech drop · inverted cp asa

ska's SLG · stock

ska's E99 · stock
skapunkin is offline View My Blog!   Reply With Quote
Old January 14th, 2006, 10:06 PM   #10 (permalink)
Certified Caffeine Addict

PizzaMiLiTiA's Avatar

Join Date: Jun 2005
Location: Biloxi, Mississippi
Posts: 3,072
Quote:
Originally Posted by skapunkin
In place of 300/600 sand paper or in conjunction with?
After the sanding.
PizzaMiLiTiA is offline View My Blog!   Reply With Quote
Old January 15th, 2006, 01:12 PM   #11 (permalink)
Registered User

Join Date: Jan 2006
Posts: 16
So how much does it really help the gun? Is it worth it?
aatheodo2 is offline View My Blog!   Reply With Quote
Old January 15th, 2006, 03:12 PM   #12 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
IT helps quite a bit and it helped reduce some of the kick back and i got more shots from the a tank

But the gun i used for pictures kept shooting over 300 fps till I installed a reg cause I did a little it a little too well. SO you may have to either have the drive spring cut or screw the velocity adjuster all the way in
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche
Mortisdeum is offline View My Blog!   Reply With Quote
Old January 15th, 2006, 03:56 PM   #13 (permalink)
crippler

Drew-Unit's Avatar

Join Date: Dec 2005
Location: Ontario, Canada
Posts: 42
I just polished mine. it took 1.5 hours, and everything went smoothly. I just tried it in my back yard and it is shooting really hard, so I'll have to turn the velocity down a bunch. thanks for the instructions Mortisdeum.
__________________
An eye for eye only ends up making the whole world blind.
~Mohandas Gandhi
Drew-Unit is offline View My Blog!   Reply With Quote
Old April 9th, 2006, 08:56 PM   #14 (permalink)
Senior Member

Smitty's Avatar

Join Date: Nov 2003
Location: Valley Alabama
Posts: 3,172
Good Job there Mort!

Stickey'd
__________________
If its still moving then you haven't shot it enough.
Smitty is offline View My Blog!   Reply With Quote
Old April 14th, 2006, 02:16 PM   #15 (permalink)
Buckeyes # 1

Dirdy's Avatar

Join Date: Feb 2006
Location: Hilliard, Ohio
Posts: 452
Im planning on polishing the inside of my A5 soon. But for now im just going to drop some oil down were the spring and pin are in the back of the gun....i play paintball im no mechanic lol i really gotta stop being lazy and do this tho.
__________________

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.



To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Dirdy is offline View My Blog!   Reply With Quote
Old July 18th, 2006, 10:58 AM   #16 (permalink)
Registered User

Join Date: Jul 2006
Posts: 9
So is this really worth doing? I'm looking to eliminate some kick back of the gun. Will this help?
bigreddastud is offline View My Blog!   Reply With Quote
Old July 18th, 2006, 01:04 PM   #17 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
Quote:
Originally Posted by bigreddastud
So is this really worth doing? I'm looking to eliminate some kick back of the gun. Will this help?
Yes it is worth doing but it will not noticably reduce the kick unless you lowwer the pressure the gun operates at with a reg or reduce the mass of the hammer.

The main reason you would want to do this is to get more shots from out of a tank, up the top rate of fire some, and lower the air pressure that is needed to run the gun.
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche
Mortisdeum is offline View My Blog!   Reply With Quote
Old July 18th, 2006, 01:07 PM   #18 (permalink)
Senior Member

mspainter's Avatar

Join Date: Mar 2006
Location: ct
Posts: 4,452
Awesome, but I dont have a tippy.
__________________

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.



Dual booting Windows XP Pro and Linux (Ubuntu) FTW!


Quote:
but i am a bored retard.
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.


mspainter is offline View My Blog!   Reply With Quote
Old July 25th, 2006, 08:53 PM   #19 (permalink)
What?

Arsenal98's Avatar

Join Date: Apr 2006
Posts: 59
Well I'm painting my gun and I got it sandblasted. I didnt get the inside sand blasted but some must have when through the holes and bounced back and hit the inside. Should I now polish my internals?
__________________
Dust Silver Mini
Empire Shelled Blue V35 Halo B
68/4500 LP Air America Tank
Arsenal98 is offline View My Blog!   Reply With Quote
Old July 25th, 2006, 10:10 PM   #20 (permalink)
Screaming Koala

Torch's Avatar

Join Date: Nov 2004
Location: Bentleyville, PA
Posts: 4,685
Blog Entries: 1
When mine was blasted I did afterwards, but it was taken apart before I did it so the inside really got hit more than it should have.

The inside of the body was pitted like crazy. Started with some really course sand paper, a lot rougher than you should need to use.

I can't imagine how loose it is in there now that that's all over with. Still works fine though.
__________________
"RD&D - Research, Development, and Design. - If its not broken, fix it anyway."
T.O.G. #131 - P.O.G. #16 - C.O.G. #145
Rate the:
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
-
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Torch is offline View My Blog!   Reply With Quote
Old July 30th, 2006, 02:31 PM   #21 (permalink)
Registered User

Join Date: Jul 2006
Posts: 58
great tutorial
just sanded and cleaned internals today
very smooth operation now
thanx
it is a little loose inside though

Last edited by peacefrog; July 30th, 2006 at 08:47 PM..
peacefrog is offline View My Blog!   Reply With Quote
Old July 30th, 2006, 11:55 PM   #22 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
There is one way to tighten the cocking pin but it involves drilling a hole in the hammer and then tapping it for a set screw. (have a machinest do it for you)

But aside from that the cocking pin is going to be a little loose because it's going to be loose in the hammer
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche
Mortisdeum is offline View My Blog!   Reply With Quote
Old August 1st, 2006, 02:34 PM   #23 (permalink)
Registered User

Join Date: Jul 2006
Posts: 58
i think i f**ked up.
i used metal polish that contained petroleum and petroleum damages the o-rings
will it survive?
peacefrog is offline View My Blog!   Reply With Quote
Old August 1st, 2006, 02:55 PM   #24 (permalink)
3D Airsmith

Mortisdeum's Avatar

Join Date: May 2005
Location: Northern VA
Posts: 1,689
Quote:
Originally Posted by peacefrog
i think i f**ked up.
i used metal polish that contained petroleum and petroleum damages the o-rings
will it survive?

IF you got all the polish out.
__________________
Old Projects and mods.
Tippmann Mods:

To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
,
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

[center]

“He who fights monsters should see to it that he himself does not become a monster.”
— Friedrich Nietzsche
Mortisdeum is offline View My Blog!   Reply With Quote
Old August 1st, 2006, 03:14 PM   #25 (permalink)
Registered User

Join Date: Jul 2006
Posts: 58
thank god
peacefrog is offline View My Blog!   Reply With Quote
Reply



Currently Active Users Viewing This Thread: 1 (0 members and 1 guests)

Thread Tools

Posting Rules

Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are On
Pingbacks are On
Refbacks are On


VerticalSports
Baseball Forum Golf Forum Boxing Forum Snowmobile Forum
Basketball Forum Soccer Forum MMA Forum PWC Forum
Football Forum Cricket Forum Wrestling Forum ATV Forum
Hockey Forum Volleyball Forum Paintball Forum Snowboarding Forum
Tennis Forum Rugby Forums Lacrosse Forum Skiing Forums
Copyright (C) Verticalscope Inc Powered by vBulletin® Version 3.8.8
Copyright ©2000 - 2019, vBulletin Solutions, Inc. Search Engine Optimization by vBSEO 3.6.1
